REACH Medical Grade Silicone Rubber Material Two Part Platinum High Strength

Product Categories
Guangzhou Ruihe New Material Technology Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

REACH Medical Grade Silicone Rubber Material Two Part Platinum High Strength

Brand Name : Rui-He

Model Number : RH625-0316-01

Certification : RoHS, FDA, MSDS, SGS, REACH, PAHS, ISO9001

Place of Origin : GuangZhou, China

MOQ : 100KG

Price : USD $+3-7/PER Kilograms

Payment Terms : L/C, T/T, Western Union

Supply Ability : 1200 tons per month

Delivery Time : 5-8days

Packaging Details : 20kg pails OR 200Kg / drums

Liquid silicone rubber : liquid silicone

Certificate : RoHS, FDA, MSDS, SGS, REACH, PAHS, ISO9001.

Performance : great temperature range capabilities

Physical form : Liquid silicone rubber

R & D Center : 30 persons

Application : Industrial

shelflife : within 400 days

Feature : Safety And Environmental Protection

Design : Customized as requested

Package : 20kgs/200kgs

Contact Now



Medical grade Silicone Rubber Material Two_Part Platinum_High Strength China Factory



LSR is platinum-cured and natural transparent silicone which is more transparent than solid silicone. Liquid silicone rubber can mixed with pigmentation to produce colorful LSR molded products.





The silicone products we supply include liquid silicone rubber and room temperature vulcanizing silicones.



The products are transformed into silicone elastomers through the process of vulcanization.



Our silicone rubber products deliver excellent performance in the silicone engineering range of products





Product description



Silicone rubber molding is accomplished in five different ways:



1. cast molding,

2. injection molding,

3. compression molding,

4. transfer molding

5. dip molding



Physical Property
Physical properties Testing method Unit RH6250-30 RH6250-40
Appearance

Visual

inspection

 / Transparent Transparent
Viscosity DIN53019 Pa.s

1200000-1800000

1400000-1800000
Hardness GB/T531.1 Shore A 30 40
Proportion GB/T533 g/cm3 1.08 1.10
Tensile Strength GB/T 528 Mpa 8.0 8.5
Elongation GB/T 528 % 600 550
Tear strength GB/T529 KN/m 20 25
Linear shrinkage CGB-T14235.4 % 0.1% 0.1%
Remarks



Ruihe RH6250 SERIES Liquid Silicone Rubber (F-LSR) is specifically designed for liquid injection molding.



The product is supplied as a two component, soft fluorosilicone paste. It heat cures to a 60 durometer material.



The cured rubber product is resistant to a wide variety of solvents and chemicals over a wide temperature range



of -63 to +175°C (-82° to +347°F) under immersion conditions, and up to +225°C (+437°F) in dry heat.



REACH Medical Grade Silicone Rubber Material Two Part Platinum High Strength









Application

These grades are particularly suitable for the economical production of large series of injectionmoulded articles.

Parts made from RUI-HE RH6250-50 can be used for technical and pharmaceutical applications.

These articles are also suitable for use in conjunction with foodstuffs.

REACH Medical Grade Silicone Rubber Material Two Part Platinum High Strength



Processing

Mixing

Rui-he RH 6250 series Liquid Silicone Rubber is a two-component material supplied  as parts A and B,

which should be combined in a 1:1 ratio. Meter mix equipment which  pumps, meters, and mixes

the two components without the incorporation of air is strongly  recommended for production.


Pot Life

After the A and B components are mixed,  Liquid Silicone  Rubber will remain usable for at least 48 hours at room temperature.

REACH Medical Grade Silicone Rubber Material Two Part Platinum High Strength

Storage

The 'Best use before end' date of each batch is shown on the product label.

Storage beyond the date specified on the label does not necessarily mean that the product is no longer usable.

In this case however, the properties required for the intended use must be checked for quality assurance reasons.


Physical properties Testing method Unit RH6250-40A/B RH6250-50A/B RH6250-60A/B RH6250-70A/B RH6250-71A/B
Appearance Visual inspection / Transparent
Viscosity DIN53019 Pa.s 1200 1200 1500 2000 2500/
Hardness GB/T 531.1 Shore A 40 50 60 65 70
Density

GB/T

533

 g/cm3 1.11 1.12 1.12 1.13 1.13
Resilience

GB/T

1681

 % 55 65 60 55 55
Tensile Strength GB/T 528-2009 Mpa 7.5 9 9.5 9.5 9
Elongation GB/T 528 % 550 550 500 400 350
Tear Strength GB/T 529 KN/m 25 30 35 30 25
Tensile Set GB/T 528 % 2.6 1.7 1.7 0.8 0.8
Linear shrinkage CGB-T14235.4 % 2.5 2.6 2.6 2.5 2.5





REACH Medical Grade Silicone Rubber Material Two Part Platinum High Strength



REACH Medical Grade Silicone Rubber Material Two Part Platinum High Strength



CONTACT US

For more than 15 years, OEM designers and maintenance and materials engineers around the world have trusted
the Rui-he brand for performance and expertise to solve or prevent sealant challenges.

Rui-he has sales offices, manufacturing sites, and science and technology laboratories – and a network of more than 200.

To learn more about our extensive product and service offerings, order samples, visit lsrliquidsiliconerubber.com
 email: chenp8008@@gmail.com or call  at(wechat//whatsapp) +86 136 6016 5505.
